پنل خورشیدی مونوکریستال دوطرفه تریناسولار ۷۰۵ وات

Peak Power Watts-Pmax(Wp)

705W

Power Selection

0~+5 w

Maximum Power Voltage - Vmpp

40.7 V

Maximum Power Current-Impp

17.33A

Open Circuit Voltage - Voc

48.8 V

Short Circuit Current - Isc

18.36 A

Module Efficiency

22.7%

Peak Power Watts-Pmax/Backside Power Gain 5%

740W

Peak Power Watts-Pmax/Backside Power Gain 10%

776 W

Maximum Power Voltage -Vmpp/Backside Power Gain 5%

40.7v

Maximum Power Voltage -Vmpp/Backside Power Gain 10%

40.7v

Maximum Power Current -Impp/Backside Power Gain5%

18.20A

Maximum Power Current -Impp/Backside Power Gain 10%

19.06A

Open Circuit Voltage -Voc/Backside Power Gain 5%

48.8v

Open Circuit Voltage -Voc/Backside Power Gain 10%

48.8v

Short Circuit Current -Isc/Backside Power Gain 5%

19.28A

Short Circuit Current -Isc/Backside Power Gain 10%

20.20

Nominal Operating Cell Temperature

42°c(+-2°c)

Temperature coefficient of Pmax

-0.29%/°c

Temperature Coefficient of Voc

-0.24%/°c

Temperature Coefficient of Isc

0.04%/°c

Operating Temperature Range

-40~+85°c

Maximum System Voltage

1500VDC

Max Series Fuse Rating

35A

Nomber of cells

132cells

Solar Cell

N-type i-TOPCon Monocrystalline

Weight

38.3kg

Module Dimensions

2384*1303*33 mm

j-Box

IP68 rated

Packing

Module Per Box 33 pieces
